ORION (4/4) 4 COLOUR 4 STATION Floor Standing Micro Registration

ORION - 4/4 Floor Standing Carousel

One of the most recognizable popular models, not only due to its affordability but also its strength, accuracy and reliability.  The Orion 4 Colour 4 Station Manual Floor Standing Carousel maximizes production levels in every print room.  A quality, robust carousel built to last and tackle every job it undertakes.  Whether you are upgrading from a tabletop carousel or not quite ready for the 6/6 (Pegasus), this carousel has proven its strength, consistency and endurance in many printing workshops.

• Ideal Start Up Carousel
• Superior Print Quality
• Keep Costs Low
• Sturdy & Rigid achieve consistent prints where registration is crucial.
• High Quality Bearings that lock print heads in place.
• Small Footprint Allows for smaller spaces, workshops, garages, home - setups.
• Use in conjunction with a floor standing flash dryer for fast production.
• Manual Carousel
• Dimensions: (L*W*H): 2270*2270*1050mm
• Weight 120 kg
• Printing Surface: Flat
• Average Printing Speed: 500pcs/Hour
• Maximum print size: (L*W): 400*500mm
• Print Height: 5mm
• Maximum Frame Size: 500*600mm
• Aluminium Platens A3 x 4, Highest Quality, Robust, Will never burn or warp like wooden boards!
• Print onto a variety of products: T - shirts, Clothing, Fabrics, Towel, Leather , bags, backpacks, card, paper, wood and other flat products
• The printing base can be rotated and the screen plate can turn backwards and forwards, left and right, which makes operation easier and positioning more accurate.
• Frames can be accurately set to the correct position by turning screws on the print head micro adjustment.
• Head comes assembled ready to attach to the base.
• Location lock that helps lock the arm in place whilst in the printing position.
• All tubular steel construction.
• Adjustable screen tension hold down.
